Frequency Response (-5dB) 47 Hz -19 Khz (±5dB)
Max SPL (peak) 129 dB (calculated)
Sensitivity (1W/1m) 102 dB
HF driver 1 x 3” HF Compression Driver
LF driver 1 x 12” long excursion ferrite
Impedance 8 Ohm
Nominal power 500 W
Program power 1000 W
Peak power 2000 W
Connectors 2x NL4 Speakon
Dimensions (WxHxD) 490x452x318 mm
Net weight 19 kg
Shipping weight 22 kg
Mounting Floor placement
Enclosure materials Plywood;Water-based paint
Grill Steel grill, polymere protective net
 |
 |
