TKG Sound system for stage performance DJ karaoke 231 Dual Channel 31 Band Graphic equalizer audio

Product List

Product Show

Features :

231 Dual 31 Band Graphic Equalizer
Frequency Response
Flat: 20Hz-20kHz, 0, -0.5dB
Bandwidth: 0.35Hz-80kHz, 0, -3dB
Input impedance: 40k Balanced/Unbalanced
Max Level: 22dBuOutput
Impedance: Balanced
4dBu: Balanced: 200l; Unbalanced: 100
-10dBV: Balanced: 1.5k; Unbalanced: 750
Max Level: 21dBu into 600

Side Chain Insert
Input Impedance: >10k
Output Impedance: <2k
Max Level: 21dBu
Distortion Noise: <0.2% any amount of compression at 1kHz
Intermodulation Distortion: <0.2% SMPTE
Noise: <-93dBu unweighted
Dynamic Range: >114dB, unweighted
Crosstalk: <-93dB @ 1kHz
Common Mode Rejection: >40dB (Any Frequency)
Stereo Coupling: True RMS Power Summing
Threshold Characteristics: Selectable OverEasy or hard knee
Exp/Gate: Program Dependent Threshold
Compressor: -40 to 20dB
Expander/Gate: -60 to 10 dB
Ratio: Compressor: 1:1 to :1
Expander/Gate 1:1 to 4:1

Attack Time
Compressor: Scalable Program Dependent
Expander/Gate: <100 µsec

Release Time
Compressor: Scalable Program Dependent
Expander/Gate: Program Dependent
Power Requirements:
15 Watts, 100 VAC 50/60 Hz, 120 VAC 60 Hz, 230 VAC 50/60 Hz

Dimensions
(H x W x D) 1.75″ x 5.75″ x 19″ (4.45 cm x 14.6 cm x 48.5 cm)
