Inputs
Connectors: 1/4 inch TRS, fenals XLR (pin 2 hot), and barrier terminal strip
Type: Electronically balanced/unbalanced, RF filtered
Maximum Input Level: >+21dBu balanced or unbalanced
CMRR: >40dB, typically >55dB at 1kHz
Outputs
Connectors: 1/4 inch TRS, male XLR (pin 2 hot), and barrier terminal strip
Type: Impedance-balanced/unbalanced, RF filtered
Impedance: Balanced 200 ohms, unbalanced 100 Ohms
Maximum Output Level: >+21dBU balanced/unbalanced into 2kOhms or greater
>+18dBm balanced/unbalanced (into 600 ohms)
System Performance
Bandwidth: 20Hz to 20kHz, +0.5/-1dB
Frequency Response: <10Hz to >50kHz, +0.5/-3dB
Dynamic Range:
+/-15dB Range: 109dB +-6dB Range: 115dB
Signal-to-noise Ratio:
+/-15dB Range: 90dB +-6dB Range: 97dB
THD+Noise: <0.005%
Interchannel Crosstalk: <-80dB, 20Hz to 20kHz
Function Switches
EQ Bypass: Bypasses the graphic equalizer section in the signal path
Low Cut (recessed): Activates the 40Hz 18dB/octave Bessel high-pass filter
Rance (recessed): Selects either +/-6dB to +/-15dB slider boosy/cut range
Indicators
Output Level: 4-LED bar graph (Green, Green, Yellow, Red) at -10, 0, +10, and 18dBu
EQ Bypass: 1 LED: red
Clip: 1 LED: red
Low Cut: 1 LED: red
+/-6dB: 1 LED: yellow
+/-15dB: 1 LED: red
Power Supply
Operating Voltage: 100VAC 50/60Hz, 120VAC 60Hz, 230VAC 50/60Hz
Power Consumption: 24 watts
Mains Connection: IEC receptacle
Physical
Dimensions: 5.25 x 19 x 7.9 inches (8.9 x 48.3 x 20.1 cm)
Weight: 10.6 pounds
